Acidic effluent from pickling lines, mines, plating shops and chemical plants must reach a neutral pH before discharge, and the choice of alkali decides both cost and compliance margin. Caustic calcined magnesite - reactive magnesium oxide - has become the working choice for many plants because it neutralises strongly, buffers gently, and simultaneously drops dissolved metals out of solution. This article sets out the practical dosing maths and control logic.

Why MgO Instead of Caustic or Lime

Magnesium oxide hydrates to magnesium hydroxide in water and neutralises acid from that solid surface, which means the reaction is self-limiting. Practically, MgO will not push a stream past pH 9.5-10 in normal operation, whereas sodium hydroxide routinely overshoots to pH 12 and has to be corrected with acid. Compared with hydrated lime, MgO produces less sludge volume, the sludge dewaters more easily, and the lower alkalinity load reduces scaling in pipes and pumps.

The Dose Calculation

The stoichiometry is straightforward. One kilogram of pure MgO carries about 49.6 equivalents of neutralising capacity, equivalent to roughly 1.81 kg of HCl, about 2.43 kg of H2SO4, or about 2.48 kg expressed as calcium carbonate equivalent. Take an influent at 2000 mg/L free sulphuric acid flowing at 50 cubic metres per hour: that is 100 kg of acid per hour, needing roughly 41 kg of pure MgO, corrected for grade purity and MgO losses to sludge. Always size the plant 10-20 percent above the theoretical figure.

Reactivity Sets the Retention Time

Dose alone means nothing without speed. The citric acid activity test expresses how quickly a grade dissolves: highly reactive CCM reacts in well under two minutes, medium grades take several minutes, and dead burned material barely reacts at all. If your reaction tank gives 15 minutes of retention, a slow grade will leave unreacted MgO in the sludge and force a higher dose. Plants should specify a maximum reactivity time in seconds, not just an MgO percentage.

Metal Precipitation Windows

The second benefit is metal removal. Copper, nickel, zinc and chromium all drop out as hydroxides in the pH 8.5-9.5 band, exactly where MgO naturally buffers. This matters for amphoteric metals such as zinc and aluminium, which begin to re-dissolve above pH 11 - precisely the zone a caustic system can overshoot into. Where discharge permits carry metal limits, MgO gives a genuine compliance cushion.

Feeding and Control Practice

Make up MgO as a 10-20 percent w/w slurry in a day tank with continuous agitation, since the solids settle fast. Dose with a variable-speed pump into a high-shear mix zone, measure pH downstream after at least one minute of contact, and run a PID loop with a dead band around the 8.8-9.2 setpoint. Keep a 1-2 g/L MgO excess in the tank to handle load spikes rather than chasing every fluctuation.

Jar Testing Before You Commit

Never convert a whole plant on a datasheet. Request a 2-5 kg sample, then run a bench test on real effluent: fill one-litre jars at the prevailing pH, dose incrementally, and record pH at 1, 5 and 15 minutes to see both the endpoint and the kinetics. Let the jars settle for 30 minutes, then filter and analyse the supernatant for residual metals. Compare the MgO result against your incumbent chemical on both cost per cubic metre and sludge volume.

What to Send Your Supplier

Share influent pH, flow, acid species, target outlet pH, metals present and available retention time. A competent supplier converts that into a recommended grade, mesh size and dose rate, and sends a sample for jar testing before you commit. HOLY (CNMGO Group Limited) supplies reactive CCM from Dashiqiao with documented citric acid activity, MgO content and heavy metal screening, exported from Dalian to more than 50 countries.
